Delivery distance 2,000 m with F-hose, 4,000 l/min
Hose-laying system mounted on a chassis with an innovative high-performance pump, independent of
the suction height for a 3.5-tonne trailer.
| Possible hose lengths with F 150 | |
| at 10 bar: | at 15 bar: |
| 2.000 l/min – 3.500 m | 5,500 m or a 50 m difference in altitude |
| 3.000 l/min – 2.000 m | 3,000 m or a 50 m difference in altitude |
| 4.000 l/min – 1.200 m | 1,800 m or a 50 m difference in altitude |
Comparison of a high-performance fire-fighting water supply system with a conventional fire-fighting water supply system
Pipeline length 2,000 m, fire hose with 2 Fladt high-performance pumps, 4,000 l/min, geodetic suction head 7.5 m and 100 m head difference.
Alternative arrangements
Water extraction trolley designed for FPN 10-1500 submersible firefighting pumps
to supplement pumping water over long distances
With electric submersible pumps
Example of 3,000 l/min water extraction
with “Water extraction” roller container for suction heads above 7.5 m:
With hydraulic submersible pump
With hydraulic submersible pump
